iPad Mini 1 Replacement Battery A1445 616-0627/616-0633/616-0688 | 3.72V 4440mAh LiCoO₂ for A1432/A1454/A1455
-
✅ Fits iPad Mini 1st Gen (2012–2015) — models A1432 (Wi-Fi), A1454 (GSM), A1455 (CDMA); P/N A1445, 616-0627, 616-0633, 616-0688, DAK290448-W090H01LH
-
✅ Rated 3.72V / 4440mAh / 16.5Wh — matched to OEM spec; Grade-A LiCoO₂ soft-pack cell
-
✅ Built-in PCM protection against overcharge, over-discharge, and short circuit; 0 cycle, 100% capacity-tested before shipment
-
✅ CE, FCC, RoHS certified — documentation available; UN38.3 compliant for air freight
-
✅ Factory direct — MOQ 50 pcs, mixed orders accepted; tiered pricing, custom labeling from 200 pcs
-
✅ Full installation tool kit included (spudger, Phillips #00, adhesive strips) — repair-line ready
Produktbeschreibung
The iPad Mini 1st generation (released October 2012, sold through 2015) remains one of the most repaired compact tablets in the market. Its battery — OEM part number A1445, internal Apple codes 616-0627, 616-0633, and 616-0688 — typically degrades below 80% usable capacity after 500–600 real-world charge cycles. For daily users, that translates to roughly 2–3 years of service life before noticeable runtime loss. At that point, battery replacement is the most cost-efficient repair path.
This cell is a 3.72V nominal / 4440mAh / 16.5Wh LiCoO₂ Li-Polymer soft-pack unit. Dimensions are verified at 151.22mm × 98.66mm × 2.21mm — within 0.1mm of OEM tolerances — and the ZIF connector drops directly onto the iPad Mini 1 logic board without modification.
Verified Compatible Models / Original Part Numbers:
| Device Variant | Apple Model ID | OEM P/N |
|---|---|---|
| iPad Mini Wi-Fi | A1432 | 616-0627 |
| iPad Mini Wi-Fi + Cellular (GSM) | A1454 | 616-0633 |
| iPad Mini Wi-Fi + Cellular (CDMA) | A1455 | 616-0688 |
| Battery Model Number | A1445 | DAK290448-W090H01LH |
⚠️ Not compatible with iPad Mini 2, 3, 4, or 5. Always cross-check the model number printed on the device’s back housing before committing to a bulk order.
Technische Parameter
| Parameter | Spezifikation |
|---|---|
| Battery Model / P/N | A1445 / 616-0627 / 616-0633 / 616-0688 / DAK290448-W090H01LH |
| Nennspannung | 3.72V |
| Kapazität | 4440mAh / 16.5Wh |
| Zellchemie | LiCoO₂ (Lithium-Cobalt-Oxid) |
| Zelltyp | Li-ion Polymer (soft-pack) |
| Charge Voltage (Max) | 4.20V ± 0.05V |
| Discharge Cut-off | 2,75 V |
| Lebenszyklus | ≥ 600 cycles @ 80% DOD |
| Betriebstemperatur | 0°C ~ 45°C (charge) / -20°C ~ 60°C (discharge) |
| Abmessungen | 151.22mm × 98.66mm × 2.21mm |
| Gewicht | Approx. 95g |
| Anschlusstyp | ZIF, OEM-compatible |
| Schutzschaltung | PCM (overcharge / over-discharge / short circuit) |
| Zertifizierungen | CE, FCC, RoHS, UN38.3; MSDS / SDS available on request |
| Zustand | Brand New, 0 Cycle |
| Garantie | 12 months from shipment date |
| Mindestbestellmenge | 50 pcs (mixed orders > 50 pcs accepted) |
| Lead Time (Stock) | 3–5 business days |
| Verpackung | Anti-static bag + foam box; custom retail packaging from 200 pcs |
Brauchen Sie einen zuverlässigen Versorgungsplan? Senden Sie uns Ihre Modellliste, die benötigten Mengen und den Lieferort. Wir bestätigen Ihnen Lieferzeit, Versandart und die erforderlichen Dokumente, bevor Sie die Bestellung aufgeben.
Merkmale und Vorteile
✅ 🔋 Grade-A LiCoO₂ Cells — Real 4440mAh, Not Rated
Every cell is measured at ≥ 4440mAh actual capacity prior to assembly. Cells testing below 98% of nominal are rejected at the grading stage. End users get the same runtime as a factory-new device — no capacity inflation, no filler cells.
✅ 🛡️ Three-Layer PCM Protection Circuit
The integrated PCM board cuts power at overcharge (> 4.25V), over-discharge (< 2.75V), and short circuit. This is non-negotiable for repair shop liability and end-customer safety — particularly important for school and enterprise refurbishment fleets.
✅ 📋 CE, FCC & RoHS Certified — Import-Ready
All production batches carry current CE (EU), FCC (US), and RoHS declarations. UN38.3 test reports and MSDS/SDS documents are available on request — required for legal air freight into North America, Europe, and most Asia-Pacific markets.
✅ 🔌 OEM-Spec ZIF Connector — True Plug-and-Play
Connector pitch, cable length, and housing dimensions match the original A1445 spec precisely. No re-pinning, no adapter, no fitment surprises. Tested across A1432 (Wi-Fi), A1454 (GSM), and A1455 (CDMA) board variants.
✅ 📦 B2B Ready — Low MOQ, Mixed Orders Accepted
Minimum order is 50 pcs. Mixed orders combining multiple tablet battery SKUs count toward the same MOQ threshold — ideal for repair distributors running multi-brand product lines. Custom retail packaging and private labeling available from 200 pcs.
✅ 🔧 Complete Tool Kit Included
Each unit ships with a plastic spudger, Phillips #00 screwdriver, and pre-cut adhesive strips. Repair shops can proceed directly to installation with no separate tooling to source or stock.
Verpackung & Lieferung
Lieferzeit & Versand
Lagerware: Versand innerhalb von 3 Tagen
Für Standard-Ersatzmodelle mit verfügbarem Lagerbestand.Bestellungen in Großserie: Versand innerhalb von 7 Tagen
Für reguläre Modelle gemäß bestätigten Spezifikationen und Verpackungsanforderungen.Kundenspezifische Bestellungen: Versand innerhalb von 15 Tagen
Für kundenspezifische Zellkonfigurationen, Größen, Kabel/Steckverbinder, Leiterplatten/BMS, Etikettierung oder Verpackung.
Notiz: Die endgültige Versandzeit hängt ab von Gesamtmenge, Modellkomplexität, Verpackungsanforderungen und Versandkonformitätsdokumente. Wir werden Ihnen das voraussichtliche Versanddatum bestätigen (ETD) nach Auftragsbestätigung.
Luftfracht (dringend, kleineres Volumen)
Seefracht (kostengünstig für Massengut)
Schiene / LKW (abhängig vom Bestimmungsort)
Expresskanäle
Verfügbare Dokumente: UN38.3 / Sicherheitsdatenblatt / Transportprüfbericht (falls zutreffend)
Die normgerechte Verpackung und Kartonetikettierung kann je nach gewählter Versandart arrangiert werden.
EXW / FOB / CIF / DDP verfügbar
Beschaffung aus einer Hand für das gesamte Apple-Ökosystem
Optimieren Sie Ihre Lieferkette. Fassen Sie Ihre Bestellungen für MacBook-, iPad-, iPhone- und Apple Watch-Batterien in einer einzigen Sendung zusammen, um die Logistikkosten zu senken und Ihre Großhandelsmargen zu maximieren.
Häufig gestellte Fragen
Q1: Which iPad Mini models is the A1445 battery compatible with?
A: This battery fits all iPad Mini 1st generation variants: A1432 (Wi-Fi only), A1454 (Wi-Fi + Cellular GSM), and A1455 (Wi-Fi + Cellular CDMA). The OEM part numbers it directly replaces are 616-0627, 616-0633, 616-0688, and DAK290448-W090H01LH. It does not fit iPad Mini 2, 3, 4, or 5 — those use different form factors and connector pitches. Always verify the model number on the back housing before ordering.
Q2: How long does an iPad Mini 1 battery last after replacement?
A: Under typical mixed use — web browsing, video playback, light gaming — a properly installed 4440mAh replacement battery delivers approximately 8–10 hours of screen-on time, consistent with Apple’s original specification for the iPad Mini 1. Battery longevity post-replacement depends on charge habits: avoid full discharge cycles and high-heat storage to maintain cell health beyond 600 cycles.
Q3: Does the A1445 replacement battery need activation or calibration after installation?
A: No special activation is required. For the battery percentage gauge to read accurately from the first use, run 2–3 full charge-discharge cycles after installation — charge to 100%, discharge to approximately 5%, then recharge fully. This calibrates the fuel gauge IC. The cell itself operates at full capacity from cycle one.
Q4: What certifications does this battery carry, and are compliance documents available?
A: Each production batch carries CE (EU), FCC (US), and RoHS certifications. UN38.3 test reports are available for air shipment compliance. MSDS and SDS documentation is provided on request. These documents are required for legal import into the US, EU, UK, and most regulated Asia-Pacific markets — we supply them routinely with bulk orders.
Q5: What is the MOQ for wholesale orders, and can I mix with other SKUs?
A: The MOQ is 50 pcs. Mixed orders combining this SKU with other tablet battery models from our catalog count toward the same 50-pcs threshold — no per-SKU minimums. For orders from 200 pcs, we offer custom labeling and retail-ready packaging. Free samples (buyer covers freight) are available before any volume commitment.
Q6: What is the warranty and defect policy for bulk orders?
A: All units carry a 12-month warranty from the shipment date. Our DOA rate is controlled below 0.3% per batch. Any confirmed defective units within the warranty period are replaced or credited at our cost. We conduct 100% capacity testing and PCM function verification before shipment — test reports can be included with each delivery batch on request.
